| Casses | ||
|---|---|---|
| Cases | Plastic Ruggedized Waterproof (IP65) | Data Network |
| Supported Air Interfaces | LTE 4G 3G |
|
| Frequency Bands | 3G/4G | 850/ 900/ 1800/ 1900 MHz |
| UMTS WCDMA/ HSUPA/ HSDPA | 850/ 1900/ 2100 MHz | |
| Cellular Module | Built-in | Only requires SIM card |
| Cellular Antenna | Option 1: External Option 2: Internal |
Option 1: External SMA Connector Option 2: Internal Connection |
| Frequency | 850/ 900/ 1800/ 1900/ 2100 MHz | |
| Bandwidth control | Automatic | Video |
| Video Input | 2 x Video Input | 2.5mm TRRS Female Socket for Video Input/ 5V Power Output |
| Supported Cameras | Any Analogue Camera | PAL/ NTSC |
| Video compression | H.264 Dual Encoding | Streaming/ recording |
| Video Resolution | CIF/ D1 | Remote User Control |
| Video Bit rate | From 10kbit/s to 2Mbit/s | Remote User Control |
| Video Frame rate | Up to 25/30 fps | Remote User Control |
| Supported PTZ Cameras | Analogue | PAL/ NTSC |
| Protocol | Pelco D or Visca | |
| Baud Rates | 1200/ 1800/ 2400/ 4800/ 9600/ 19200/ 38400/ 57600/ 115200/ 230400 |
|
| PTZ Control | RS-485 Wires (T+, T-) | Through Cable Interface | Audio |
| Audio Input | Built-in microphone or Line in | 2.5mm TRRS Female Socket for Audio Line In/ Line Out |
| Audio output | Built-in speaker or Line out | 2.5mm TRRS Female Socket for Audio Line In/ Line Out |
| Audio compression | AAC | Location |
| GPS/GLONASS Receiver | Built-in | Updates every few seconds |
| Frequency Band | 1575.42 MHz | |
| GPS Antenna | External | SMA Connector |
| Frequency | 1575.42 MHz | |
| Waterproof | Yes (IP67) | |
| Alarm Button | ||
| Push Button | On Surface | |
| Event Triggers | Multiple Trigger Actions | Streaming/ Recording/ SMS/ Noise/ GPS Tracking | Storage |
| Built-in Storage | Capacity | 128MB |
| Micro SD Slot | Up to 256GB (FAT32 format) | Max bit rate based on micro SD write speed | GPIO |
| Input | 4x Input Sensor Ports | Built-in (Through External Cable Interface) |
| Logic Level | TTL | |
| User Settings Control | Active Low/ Active high | |
| Multiple Trigger Actions | Streaming/ Recording/ SMS/ Noise/ GPS Tracking | |
| Output | 4x Output Ports | Built-in (Through External Cable Interface) |
| Logic Level | TTL | |
| Switching | Through MRS Monitor Software | |
| Multiple Trigger Actions | Streaming/ Recording/ SMS/ Noise/ GPS Tracking | Power |
| Power Input | 5V (Max) | AC-DC 5V adapters |
| Power Consumption | 500-1500mA while streaming | |
| Battery | Built-in/ Lithium | 4200mAh |
| Power Output | 5V Output to Camera | Environment |
| Temperature Input (approximatly) | -10 +60°C | Physical |
| Dimension | 5 x 10 x 2.8 cm | |
| Weight | 130 g | Other Interfaces |
| USB Client | Built-in (Mini USB Input) | For Setup/ Configuration (Through USB Cable and PC) |
| GPIO/PTZ Cable | Interface Cable for GPIO/PTZ | Multi Coloured Wires |
| Video/Power Adapter Cable | Splitter cable for Video Input/ 5V Power Output |
TRRS Male Jack to RCA/DC Connectors |
| Audio In/Out Adapter Cable | Splitter cable for headphones/ Mic | TRRS Male Jack to TRS Female Connectors |
| LAN | Built-in through external cable interface |
10/100 Ethernet | Protocols |
| RTP/ RTSP/ SDP | ||
